Chatillon DFX2-200 Digital Force Gauge - 200 x 0.2 lbf
The DFX II is available in four capacities (10lbf, 50 lbf, 100 lbf, 200 lbf) and features an integral loadcell with a measurement accuracy of better than 0.3% full scale. The DFX Series operates using a rechargeable NiMH battery pack and can operate using the supplied universal charger as well. more ...
  Price Drop Alert
Chatillon DFX2-200 Digital Force Gauge -  200 x 0.2 lbf
Chatillon DFX2-200 Digital Force Gauge - 200 x 0.2 lbf
FREE Next Day Air Shipping *


Price: $676.40


In Stock - Ships within 24 hours

Optional Accessories
Chatillon SPK-FMG-013A Extension Rod, Low Capacity  (#10-32) Chatillon SPK-FMG-013A Extension Rod, Low Capacity (#10-32) , $26.00
Chatillon SPK-FMG-010A Notch Adapter 100 lbf (500 N) Chatillon SPK-FMG-010A Notch Adapter 100 lbf (500 N) , $18.00
Chatillon SPK-FMG-009A Point Adapter  100 lbf (500 N) Chatillon SPK-FMG-009A Point Adapter 100 lbf (500 N) , $18.00
Chatillon SPK-FMG-008A Chisel Point Adapter 100 lbf (500 N) Chatillon SPK-FMG-008A Chisel Point Adapter 100 lbf (500 N) , $18.00
Chatillon SPK-DF-HANDLE Handle Assembly Chatillon SPK-DF-HANDLE Handle Assembly , $65.00
Chatillon SPK-FMG-141 Pistol Grip Chatillon SPK-FMG-141 Pistol Grip , $93.00
Chatillon SPK-FMG-013B Extension Rod, 6-inch 500 lbf Thread 5/16-18F Chatillon SPK-FMG-013B Extension Rod, 6-inch 500 lbf Thread 5/16-18F , $37.00
Chatillon SPK-FMG-010B Notch Adapter 500 lbf, 2.5 kN 5/16-18F Chatillon SPK-FMG-010B Notch Adapter 500 lbf, 2.5 kN 5/16-18F , $25.00
Chatillon SPK-FMG-009B Point Adapter  500 lbf, 2.5 kN 5/16-18F Chatillon SPK-FMG-009B Point Adapter 500 lbf, 2.5 kN 5/16-18F , $26.00
Chatillon SPK-FMG-008B Chisel Point Adapter 500 lbf, 2.5 kN 5/16-18F Chatillon SPK-FMG-008B Chisel Point Adapter 500 lbf, 2.5 kN 5/16-18F , $26.00
Chatillon NC002845 Soft Carrying Case, Fanny Pack Chatillon NC002845 Soft Carrying Case, Fanny Pack , $61.75
Chatillon SPK-MT-0001 Adapter Gauge to MT150 for LG and DF Series Force Gauge Models Chatillon SPK-MT-0001 Adapter Gauge to MT150 for LG and DF Series Force Gauge Models , $64.00
Chatillon SPK-MT-0004 Adapter Gauge to MT500 Chatillon SPK-MT-0004 Adapter Gauge to MT500 , $138.70
Chatillon NC002582 Adapter Gauge to TT Tester Chatillon NC002582 Adapter Gauge to TT Tester , $103.55

View Features

Chatillon Ametek
SKU: DFX2-200

Features


The CHATILLON® DFX II Series is an economical digital force gauge ideal for applications where users are interested in basic peak force measurement. The DFX is available in four capacities (10lbf, 50 lbf, 100 lbf, 200 lbf) and features an integral loadcell with a measurement accuracy of better than 0.3% full scale. The DFX Series operates using a rechargeable NiMH battery pack and can operate using the supplied universal charger as well. The battery eliminator is supplied with a US, UK and EURO style plug. Under battery operation, the DFX Series will operate for 70 to 100 hours of continuous use. A large, easy-to-read, high resolution dot matrix LCD display supports a variety of standard gauge functions including normal and peak readings. Loads are displayed in ozf, gf, lbf, kgf and N units. The display language may be setup to indicate in English, Spanish, French, German, Portuguese and Chinese. The DFX Series’ calibration procedure is included in the gauge’s setup. The DFX Series force gauges come with a carrying case, universal battery charger, flat and hook adapters. The DFX Series is supplied with an optional Certificate of Calibration with NIST data.

Power Save Mode - Gauge has a power save feature that automatically shuts down power to the gauge when there has been no activity. Saves battery life.

Units Lock - Select the desired units of measurement. Units may be “locked” to your desired measurement type: ozf, gf, lbf, kgf or N.

Load Direction Indicator - Shows the direction of load being applied to the internal sensor

Simple Keypad - Gauge operation simple using fours keyes: Peak, Units, Zero and Info.

  • PEAK- change from Normal to Peak mode
  • UNITS- select desired units of measurement
  • ZERO- used to zero or tare
  • INFO- for gauge setup and status reviews<

Battery Status - View the current battery power remaining on your rechargeable battery pack

Normal Display - Shows the current load being applied to the sensor. Indicates load direction

Peak Display - Shows the peak (maximum) load that was applied to the sensor during a test.

Overload Display - Shows the overload history for the force gauge. Indicates the number of overloads that occurred in both the tension and compression direction

Load Bargraph - Shows the load being applied to the internal sensor graphically. Indicates overload conditions and zero offset

Rugged Construction - Cast aluminum housing and integral mechanical overload protection are designed into the DFX.

Simple Accessory Connection - Gauge has either #10-32 or 5/16-18 male threads depending on gauge capacity. Supplied standard with Flat adapter and Hook. A wide assortment of optional accessories are available

Universal Battery Charger - Universal Battery Charger includes a US, UK and EURO plug. Connects to a 120V/240V source outlet

Language Setup - Let’s you select the desired display language for your DFX. Information may be displayed in English, Spanish, French, German, Portuguese and Chinese.

Configuration Procedure - Let’s you validate or calibrate your DFX. The calibration procedure is included in the gauge setup. Just follow the step-by-step prompts.

  • Four Models
    • - (10 lbf, 50 lbf, 100 lbf, and 200 lbf)
  • Normal and Peak Operating Modes
  • Selectable Units of Measurement
    • - ozf, gf, lbf, kgf and N<
    • - Units may be locked to prevent changing
  • Measurement Accuracy
    • - Accuracy +0.3% Full Scale
    • - Mechanical Overload Protection to 150% Full Scale
  • Simple Operator Interface
    • - High Resolution Display
    • - Menus, Prompts and Dedicated Function Keys for Easy Use<
    • - Load Bargraph
  • » Selectable Display Languages
    • English, Spanish, French, German, Portuguese and Chinese
  • Battery Operated with Automatic Shutoff Power Saver
    • - 70 to 100 hours of continuous use with rechargeable NIMH battery pack
    • - Supplied with Universal Battery Eliminator (US, UK, Euro style plugs)
  • » Supplied with standard Certificate of Conformance
    • - Optional Certificate of Calibration with NIST available
  • 1 Year Warranty
Model DFX2-010 DFX2-050 DFX2-100 DFX2-200 DFX2-010-NIST DFX2-050-NIST DFX2-100-NIST DFX2-200-NIST
lbf 10 x 0.01 50 x 0.05 100 x 0.1 200 x 0.2 10 x 0.01 50 x 0.05 100 x 0.1 200 x 0.2
kgf 5 x 0.005 25 x 0.02 50 x 0.05 100 x 0.1 5 x 0.005 25 x 0.02 50 x 0.05 100 x 0.1
N 50 x 0.05 250 x 0.2 500 x 0.5 1000 x 1 50 x 0.05 250 x 0.2 500 x 0.5 1000 x 1
gf 5000 x 5 25000 x 20 50000 x 50 - 5000 x 5 25000 x 20 50000 x 50 -
ozf 160 x 0.2 x 5 800 x 1 1600 x 2 - 160 x 0.2 x 5 800 x 1 1600 x 2 -
Accuracy: ±0.3% of full scale
Certification: Certificate of Conformance (std). NIST Traceable and 17025 calibration
Data Sampling Rate 1000 Hz
Peak Capture Rate 1000 Hz
Display Update Rate 250mS
Tare Capacity 110% full scale
Overload Protection 150% full scale
Display Characteristics High resolution, dot-matrix LCD, 8 lines, 21 characters
Automatic Shut Down 30 minutes. May be disabled
Power NiMH battery pack or use with Universal Battery Charger
Battery Life
Instrument Weight 1.5 lbs (0.7 kg)
Shipping Weight 4 lbs (1.8 kg) with accessories
Warranty: 1 year
Storage Temperature 0 to 130 F (-17 to 54 C)
Operating Temperature 40 to 110 F (4 to 43 C
Temperature Stability Better than 0.03% of rated output per F
Relative Humidity 20% to 85%
Loadcell Deflection Specifications 0.010” +0.004” 0.010” +0.004” 0.010” +0.004” 0.010” +0.004” 0.010” +0.004” 0.010” +0.004” 0.010” +0.004” 0.010” +0.004”

Conformance The Chatillon DFX Series has been accessed against the essential health and safety requirements of the Low Voltage and the EMC Directives listed and found to be in compliance. BS EN 61010-1:2001 Safety Requirement for Electrical Equipment BS EN 61000-6-3:2001 EMC Generic Emission Standard BS EN 61000-6-1:2001 EMC Generic Immunity Standard


Weight: 10.00 lb
